| Mainboard Gigabyte Z890 AORUS MASTER |
| Model |
Z890 AORUS MASTER |
| CPU |
Socket LGA1851 hỗ trợ Intel® Core™ Ultra |
| Chipset |
Intel Z890 |
| Bộ nhớ |
4 khe DDR5 tối đa 256GB 9500MHz (OC)
- Kênh đôi Dual channel
- Hỗ trợ XMP, ECC Un-buffered và non-ECC Un-buffered DIMM
|
| Graphics |
2 x Thunderbolt™ 4 |
| Khe cắm mở rộng |
1 x PCIe5.0x16
1 x PCIe4.0x4
1 x PCIe3.0x1 |
| Lưu trữ |
2 x M.2 PCIe 5.0
3 x M.2 PCIe 4.0
4 x SATA - RAID 0, 1, 5, 10 NVMe & SATA |
| Ethernet |
Marvell® AQtion AQC113C 10GbE LAN chip
(10 Gbps/5 Gbps/2.5 Gbps/1 Gbps/100 Mbps) |
| Wireless & Bluetooth |
Intel® Wi-Fi 7 BE200NGW
- 802.11a, b, g, n, ac, ax, be, supporting 2.4/5/6 GHz carrier frequency bands
- Bluetooth 5.4
- Support for 11be 320MHz wireless standard |
| Cổng USB |
2 x USB4® USB Type-C sẵn backpanel
1 x USB 3.2 Type-C Gen 2x2
6 x USB 3.2 Gen 2 Type-A
8 x USB 3.2 Gen 1 (4 sẵn backpanel)
6 x USB 2.0/1.1 (2 sẵn backpanel) |
| Các cổng nội bộ bên trong |
1 x 24-pin ATX main power connector
2 x 8-pin ATX 12V power connectors
5 x M.2 Socket 3 connectors
4 x SATA 6Gb/s connectors
1 x front panel header
1 x front panel audio header
1 x USB Type-C® header, with USB 3.2 Gen 2x2 support
2 x USB 3.2 Gen 1 headers
2 x USB 2.0/1.1 headers
1 x noise detection header
1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0/GC-TPM2.0 SPI V2 module only)
1 x HDMI port (Note)
1 x power button
1 x reset button
1 x reset jumper
1 x Clear CMOS jumper
2 x temperature sensor headers
Voltage Measurement Points |
| Cổng kết nối phía sau |
1 x Q-Flash Plus button
1 x Clear CMOS button
2 x Intel® Thunderbolt™ 4 connectors (USB Type-C® ports)
6 x USB 3.2 Gen 2 Type-A ports (red)
4 x USB 3.2 Gen 1 ports
2 x USB 2.0/1.1 ports
1 x RJ-45 port
2 x antenna connectors (2T2R)
2 x audio jacks
1 x optical S/PDIF Out connector |
| Âm thanh |
Realtek® ALC1220 CODEC, DTS:X® Ultra, đa kênh 2/4/5.1/7.1, S/PDIF Out |
| Tản nhiệt |
1 x CPU fan header
1 x CPU fan/water cooling pump header
4 x system fan headers
4 x system fan/water cooling pump headers |
| LED |
4 x addressable RGB Gen2 LED strip headers
1 x RGB LED strip header |
| Theo dõi phần cứng |
Voltage detection
Temperature detection
Fan speed detection
Water cooling flow rate detection
Fan fail warning
Fan speed control |
| Hệ điều hành |
Windows 11 64-bit |
| BIOS |
1 x 256 Mbit flash
Use of licensed AMI UEFI BIOS
PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0 |
| Dạng thiết kế |
ATX Form Factor
30.5cm x 24.4cm |
