| Bộ vi xử lý (CPU) |
| Tên bộ vi xử lý |
Intel® Core™ i5-13400F Processor |
| Tốc độ |
Up to 4.60GHz, 10 Cores, 16 Threads
P-Cores: 6 Cores, 12 Threads, 2.50GHz Base, 4.60GHz Turbo
E-Cores: 4 Cores, 4 Threads, 1.80GHz Base, 3.30GHz Turbo |
| Bộ nhớ đệm |
L1: 80KB, L2: 1280KB, L3: 20MB |
| Socket |
Intel LGA1700 |
| Mainboard (Bo mạch chủ) |
| Main |
Asus TUF GAMING B760M-PLUS WIFI II (chạy ram D5) |
| Chipset |
Intel® B760 Chipset |
| Bộ nhớ trong (RAM Desktop) |
| Dung lượng |
Ram Kingston 16GB D5-5200 40-40-40 BEAST BLack (KF552C40BB-16) |
| Số khe cắm |
4 x DIMM slots, Max. 192GB, DDR5 7800+(OC)/7000(OC)/6800(OC)/6600(OC)/6400(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600/ 5400/ 5200/ 5000/ 4800 Non-ECC, Un-buffered Memory*
Dual Channel Memory Architecture
Supports Intel® Extreme Memory Profile (XMP)
OptiMem II |
| Ổ đĩa cứng |
| Dung lượng |
SSD TeamGroup TM8FP6001T0C101 M2-2280 PCI-E Gen3x4 MP33 1TB |
| Khả năng nâng cấp |
Supports 3 x M.2 slots and 4 x SATA 6Gb/s ports*
Intel® Core™ Processors (14th & 13th & 12th Gen)
M.2_1 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode)
Intel® B760 Chipset
M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode)
M.2_3 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x2 mode)
4 x SATA 6Gb/s ports
* Intel® Rapid Storage Technology supports SATA RAID 0/1/5/10. |
| Ổ đĩa quang (ODD) |
| |
|
| Đồ Họa (Card màn hình) |
| |
Gigabyte 12GB GV-N3060WF2OC-12GD |
| Tản nhiệt |
| |
Tản nhiệt khí ID-COOLING FROZN A620 PRO SE ARGB |
| Case |
| |
Xigmatek Fly II Arctic 3GF EN44670 (ATX, Micro-ATX, ITX) |
| Nguồn |
| |
Antec Atom B650 EC (200V-250V, 650W) |
| Kết nối |
| USB |
Rear USB (Total 8 ports)
1 x USB 20Gbps port (1 x USB Type-C®)
1 x USB 10Gbps port (1 x Type-A)
2 x USB 5Gbps ports (2 x Type-A)
4 x USB 2.0 ports (4 x Type-A)
Front USB (Total 8 ports)
1 x USB 10Gbps connector (supports USB Type-C®)
1 x USB 5Gbps header supports 2 additional USB 5Gbps ports
3 x USB 2.0 headers support 5 additional USB 2.0 ports |
| Audio |
Realtek 7.1 Surround Sound High Definition Audio CODEC
- Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking
- Supports up to 24-Bit/192 kHz playback
Audio Features
- Audio Shielding
- Rear optical S/PDIF out port
- Premium audio capacitors
- Dedicated audio PCB layers |
| Cổng I/O mặt sau |
1 x USB 20Gbps port (1 x USB Type-C®)
1 x USB 10Gbps port (1 x Type-A)
2 x USB 5Gbps ports (2 x Type-A)
4 x USB 2.0 ports (4 x Type-A)
1 x DisplayPort
1 x HDMI™ port
1 x Wi-Fi Module
1 x Realtek 2.5Gb Ethernet port
5 x Audio jacks
1 x Optical S/PDIF out port |
| Đầu nối I/O bên trong |
I/O Connectors Fan and Cooling related
1 x 4-pin CPU Fan header
1 x 4-pin CPU OPT Fan header
1 x 4-pin AIO Pump header
3 x 4-pin Chassis Fan headers
Power related
1 x 24-pin Main Power connector
2 x 8-pin +12V Power connectors
Storage related
3 x M.2 slots (Key M)
4 x SATA 6Gb/s ports
USB
1 x USB 10Gbps connector (supports USB Type-C® )
1 x USB 5Gbps header supports 2 additional USB 5Gbps ports
3 x USB 2.0 headers support 5 additional USB 2.0 ports
Miscellaneous
3 x Addressable Gen 2 headers
1 x Clear CMOS header
1 x Front Panel Audio header (AAFP)
1 x 20-3 pin System Panel header with Chassis intrude function
1 x Thunderbolt™ (USB4®) header |
| Graphics |
1 x DisplayPort**
1 x HDMI™port***
* Graphics specifications may vary between CPU types. Please refer to www.intel.com for any updates.
** Supports max. 4K@60Hz as specified in DisplayPort 1.4.
***Supports 4K@60Hz as specified in HDMI 2.1. |
| Expansion Slots |
Intel® Core™ Processors (14th & 13th & 12th Gen)*
1 x PCIe 5.0 x16 slot
Intel® B760 Chipset
1 x PCIe 4.0 x4 slot
1 x PCIe 3.0 x1 slot
- To ensure compatibility of the device installed, please refer to https://www.asus.com/support/ for the list of supported peripherals. |
| Wireless & Bluetooth |
Wi-Fi 6E
2x2 Wi-Fi 6E (802.11ax)
Supports 2.4/5/6GHz frequency band*
Bluetooth® v5.3**
* Wi-Fi 6GHz frequency band regulatory may vary between countries.
** The Bluetooth version may vary, please refer to the Wi-Fi module manufacturer's website for the latest specifications. |
| Ethernet |
1 x Realtek 2.5Gb Ethernet
TUF LANGuard |
| Form Main |
| |
mATX Form Factor
9.6inch x 9.6 inch (24.4 cm x 24.4 cm) |
| Hệ điều hành |
| Hệ điều hành |
None |
| Hệ điều hành tương thích |
Windows® 11, Windows® 10 64-bit |
| |
