| Bộ vi xử lý (CPU) |
| Tên bộ vi xử lý |
Intel® Core™ i5-14400 Processor |
| Tốc độ |
Up to 4.70GHz, 10 Cores, 16 Threads
P-Cores: 6 Cores, 12 Threads, 2.50GHz Base, 4.70GHz Turbo
E-Cores: 4 Cores, 4 Threads, 1.80GHz Base, 3.50GHz Turbo |
| Bộ nhớ đệm |
L1: 80K, L2: 2MB, L3: 20MB |
| Socket |
Intel LGA1700 |
| Mainboard (Bo mạch chủ) |
| Main |
MSI B760M GAMING WIFI D5 |
| Chipset |
Intel® B760 Chipset |
| Bộ nhớ trong (RAM Desktop) |
| Dung lượng |
Ram PC Geil SPEAR V 16GB DDR5 5200 Black (GASB516GB5200C38BSC) |
| Số khe cắm |
2x DDR5, Maximum Memory Capacity 128GB
Memory Support DDR5 8000+(OC)/ 7800(OC)/ 7600(OC)/ 7400(OC)/ 7200(OC)/ 7000(OC)/ 6800(OC)/ 6600(OC)/ 6400(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(OC)/ 5400(OC)/ 5200(OC)/ 5000(OC)/ 4800(JEDEC) MHz
Max. overclocking frequency:
• 1DPC 1R Max speed up to 8000+ MHz
• 1DPC 2R Max speed up to 6400+ MHz
Supports Intel® XMP 3.0 OC
Supports Dual-Controller Dual-Channel mode
Supports non-ECC, un-buffered memory |
| Ổ đĩa cứng |
| Dung lượng |
SSD Apacer AS2280P4U M.2 PCIe 512GB |
| Khả năng nâng cấp |
2x M.2
M.2_1 Source (From CPU) supports up to PCIe 4.0 x4 , supports 2280/2260/2242 devices
M.2_2 Source (From Chipset) supports up to PCIe 4.0 x4 / SATA mode, supports 2280/2260/2242 devices
4x SATA 6G
* SATA7 will be unavailable when installing M.2 SATA SSD in the M2_2 slot. |
| Ổ đĩa quang (ODD) |
| |
|
| Đồ Họa (Card màn hình) |
| |
Intel® UHD Graphics 730 |
| Tản nhiệt |
| |
|
| Case |
| |
Xigmatek DUO X 3F EN45127 (E-ATX, ATX, Micro-ATX, ITX) |
| Nguồn |
| |
Xigmatek X-POWER X-650 EN45990 (600W, 230v) |
| Kết nối |
| USB |
2x USB 2.0 (Rear)
4x USB 2.0 (Front)
4x USB 5Gbps Type A (Rear)
2x USB 5Gbps Type A (Front) |
| Audio |
Realtek® ALC897 Codec
7.1-Channel High Definition Audio
Supports S/PDIF output |
| Cổng I/O mặt sau |
VGA
Keyboard / Mouse
2.5G LAN
Wi-Fi / Bluetooth
Audio Connectors
HDMI™
DisplayPort
USB 2.0
USB 3.2 Gen 1 5Gbps (Type-A) |
| Đầu nối I/O bên trong |
1x Power Connector(ATX_PWR)
1x Power Connector(CPU_PWR)
1x CPU Fan
2x System Fan
2x Front Panel (JFP)
1x Chassis Intrusion (JCI)
1x Front Audio (JAUD)
1x Com Port (JCOM)
2x Addressable V2 RGB LED connector (JARGB_V2)
1x RGB LED connector(JRGB)
1x TPM pin header(Support TPM 2.0)
4x USB 2.0 ports
2x USB 5Gbps Type A ports |
| Graphics |
1x HDMI™
Support HDMI™ 2.1 with HDR, maximum resolution of 4K 60Hz*
1x DisplayPort
Support DP 1.4, maximum resolution of 4K 60Hz*
1x VGA
Support VGA, maximum resolution of 2048x1536 50Hz, 2048x1280 60Hz, 1920x1200 60Hz*
*Available only on processors featuring integrated graphics. Graphics specifications may vary depending on the CPU installed. |
| Expansion Slots |
1x PCI-E x16 slot
1x PCI-E x1 slot
PCI_E1 Gen PCIe 4.0 supports up to (From CPU)
PCI_E2 Gen PCIe 4.0 supports up to (From Chipset) |
| Wireless & Bluetooth |
Intel® Wi-Fi 6E
The Wireless module is pre-installed in the M.2 (Key-E) slot
Supports MU-MIMO TX/RX, 2.4GHz / 5GHz / 6GHz* (160MHz) up to 2.4Gbps
Supports 802.11 a/ b/ g/ n/ ac/ ax
Supports Bluetooth® 5.3, FIPS, FISMA
* Wi-Fi 6E 6GHz may depend on every country’s regulations and will be ready in Windows 11.
** Bluetooth 5.3 will be ready in Windows 10 build 21H1 and Windows 11. |
| Ethernet |
Realtek® RTL8125B 2.5Gbps LAN |
| Form Main |
| |
mATX
220mmx243.84mm |
| Hệ điều hành |
| Hệ điều hành |
None |
| Hệ điều hành tương thích |
Support for Windows® 11 64-bit, Windows® 10 64-bit |
| |
